Platform Basket 18.95
- Working Height: 60'
- Outreach: 31'5"
- Width: 31"
- Weight:5,600 lbs
Specifications
Brochure
Chart
Specifications
Specifications
Max. working height
60'
Max. outreach
31’5”
Max. basket load
507 lbs
Basket size
2’3” x 2'3" (1-man basket)
Basket rotation
+ / - 90°
Turret rotation
360° non-continuous
Traveling length
14'3" (16'5" with basket)
Traveling height
6’6” narrow mode / 7’3” wide mode
Traveling width
2’7” narrow mode / 3’6” wide mode
Operational width
Outrigger spread - 10'2" x 12'1"
Battery
110V Emergency Descent System
Engine
Honda Gasoline, 13 HP
Total weight
5,600 lbs
Gradability, max. across slope up
31% (17°)
Gradability, max. up and down slope
29% (16°)
Deployment ability on slopes up to
31% (17°)
